Overview

An access door gives service access to plumbing, valves, wiring and equipment behind walls and ceilings while keeping the opening closed and finished. This Acudor AS-9000 door is 18in x 18in. Construction, per Acudor — door: Stainless Steel or Steel; hinge: Concealed. Latch: Stainless steel screwdriver operated cam latch (optional: Cylinder lock & key, allen head cam latch, spanner head cam latch). Finish: Stainless steel: #4 satin polish.Steel: 5 stage iron phosphate with prime coat of White alkyd baked-on enamel.

Product Description
AS-9000 - Gasketed Access Door

Designed to provide a gasketed fit in all types of walls and ceilings This door is commonly used in clean rooms, laboratories, operating rooms, etc.

18in x 18in, Gasketed Access Door
(457.2mm) x (457.2mm)

AS-9000 Product Features

• Gasketed access door
• Formed door panel with reinforced edges and a concealed hinge, along with open cell gasket between the door and frame

AS-9000 Access Door Specifications:

• Door / Door Frame: Stainless Steel or Steel
• Hinge: Concealed
• Gasket: Pemko S88 adhesive-backed bulb silicone gasket
• Standard Latch: Stainless steel screwdriver operated cam latch
• Optional Latches/Locks: Cylinder lock & key, allen head cam latch, spanner head cam latch
• Finish: Stainless steel: #4 satin polish.Steel: 5 stage iron phosphate with prime coat of White alkyd baked-on enamel

Please note the AS-9000 has not been tested for air penetration. For a door that has been tested for Air &Water penetration see ADWT model.

Technical Documentation:

• Product Information
• Submittal
• 3D View, Plan, Elev, & Schedule
• BIM
• Archicad
