Overview
An access door gives service access to plumbing, valves, wiring and equipment behind walls and ceilings while keeping the opening closed and finished. This Acudor door. Construction, per Acudor — door: 16 gauge recessed 5/8" lined with self-furring galvanized lath; frame: 14 gauge expansion casing bead with 3" wide galvanized lath, recessed 3/4" to receive plaster; hinge: Concealed, pivoting rod type. (For wall applications, a continuous exposed piano hinge is suggested). Latch: Flush to surface, Slotted Screwdriver Cam Latch. Finish: Baked White Prime Coat.(Additional finish paint is recommended for superior corrosion resistance).
AP-5010 18 in. x 18 in. Recessed Access Door for Acoustical Plaster Walls and Ceilings, Steel
The Acudor AP-5010 Recessed Access door is designed for use in acoustical plaster walls and ceilings
Application:
- Designed for use in acoustical plaster walls and ceilings.
Product Features:
- Door is recessed 5/8" and is lined with self-furring lath
- Expansion casing bead with 3” wide galvanized lath
- Concealed, pivoting rod type hinge
Specifications:
- Material: Steel
- Door: 16 gauge recessed 5/8" lined with self-furring galvanized lath.
- Door Frame: 14 gauge expansion casing bead with 3" wide galvanized lath, recessed 3/4" to receive plaster.
- Hinge: Concealed, pivoting rod type. (For wall applications, a continuous exposed piano hinge is suggested).
- Standard Latch: Flush to surface, Slotted Screwdriver Cam Latch.
- Optional Latches/Lock: Cylinder lock and key, allen head cam latch, spanner head cam latch.
- Finish: Baked White Prime Coat.(Additional finish paint is recommended for superior corrosion resistance).
Technical Documentation:
-
